BWT Bolero RF 1-1/2" Backwash Water Filter

Part No.: 10367

Product Overview

The BWT Bolero RF 1-1/2" Backwash Water Filter is a high-capacity whole-house sediment filtration system designed for large residential and light commercial water installations. Installed at the main water inlet, it removes rust, sand, metal chips, and coarse debris that can damage plumbing and appliances.

This model features a manual backwash cleaning system with a 90 µm reusable filter element, allowing contaminants to be flushed out without disposable cartridges. The robust design supports both horizontal and vertical installation.

Features & Benefits

• High-capacity whole-house sediment filtration
• Designed for high-flow residential and light commercial systems
• Removes rust, sand, and particles larger than 90 µm
• Manual backwash cleaning with reusable filter element
• No disposable cartridges required
• Supports horizontal or vertical installation
• Transparent housing for easy inspection
• Integrated date ring for maintenance tracking
• Slip-clutch backwash knob protects internal components
• Durable brass filter head

Specifications

• Brand: BWT
• Series: Bolero RF
• Product Type: Manual backwash water filter
• MPN / Part Number: 10367
• Connection Size: 1-1/2" (DN40)
• Filtration Rating: 90 µm
• Flow Rate @ Δp 0.2 bar: 10.5 m³/h (46.2 gpm)
• Flow Rate @ Δp 0.5 bar: 15.5 m³/h (68.2 gpm)
• Operating Pressure: 2.5–16 bar (36.2–232 psi)
• Installation Orientation: Horizontal or vertical
• Pressure Reducer: Not included

Installation Tips

1. Install after the water meter on the main incoming line.
2. Ensure sufficient clearance for manual backwashing.
3. Connect the backwash outlet to an approved drain.
4. Protect from frost, UV exposure, and excessive heat.
5. Backwash regularly based on water quality.
